ObservIR LRF 60-1280 12um Fusion Thermal Binocular 60mm

ObservIR LRF 60-1280 12um Fusion Thermal Binocular 60mm

$7,495.00

**Export Compliance Notice**
By adding to cart, you acknowledge that you are a U.S. person, do not intend to export this product, and comply with all ITAR and EAR restrictions and regulations.

AGM ObservIR LRF 60-1280 Fusion Thermal Imaging & CMOS Binocular with built-in Laser Range Finder, 12 Micron 1280x1024 (50 Hz), 4K, 60 mm lens (OBSE60-1280)

The AGM ObservIR LRF Thermal & Digital Day/Night Vision binocular is one of the most advanced and feature-rich optics available today. Its core functionality comes from the main thermal viewing channel, which boasts a high-sensitivity 12-micron detector. Unlike many other thermal binoculars, the ObservIR LRF includes an additional digital day/night channel, making it especially useful for identifying targets first detected by the thermal channel. The built-in 1,000-meter laser rangefinder elevates its capabilities even further, complemented by 64GB of internal storage and Wi-Fi compatibility.

The ObservIR LRF binocular model also integrates extensive software enhancements and a suite of features that are now standard in AGM's thermal lineup. These include a high-sensitivity thermal detector, a 25mm Germanium lens with a 1.0 aperture, a 3840x2160 ultra-low light CMOS sensor, multiple viewing modes, diverse color palettes, up to 4X digital zoom, picture-in-picture mode, a built-in laser rangefinder, GPS module, long-range IR illuminator, and up to 8 hours of battery life using removable, rechargeable 18650 batteries. Additional features include a USB Type-C port for external power, an IP67 waterproof rating, and a package that comes with four 18650 batteries, a wrist strap, and a charger.

AGM ObservIR LRF 60-1280 Features:

Dual-spectrum thermal and digital day/night system
12μm high-sensitivity thermal sensor
1280x1024 thermal resolution
2.5x – 28x thermal magnification
Digital image processing technology
Ultra-low illumination optical channel
3840×2160 optical resolution
Built-in IR illuminator
Eye-safe 1,000 m laser rangefinder
1920×1080 resolution, 0.49-inch OLED display
Digital Magnetic Compass
Built-in GPS module
Video/audio recording and snapshot capture
Built-in 64 GB EMMC storage
Wi-Fi hotspot
Standby mode
8-hour continuous operation on a single charge
Auto screen-off function to saving energy
External power supply capability
Rugged housing with rubber overmolding
Waterproof and dustproof
5 Year Warranty

AGM ObservIR LRF 60-1280 Specifications:

Interpupillary Distance

60 mm to 74 mm

Safety Class for Laser

Class 1

Palettes

Black Hot, White Hot, Red Hot, Fusion

Dimensions

232 × 153 × 82 × mm (9.1 × 6.0 × 3.2 in)

Infrared Illuminator

Built-in 850nm Smart IR.Power and beam angle adjustment.

Distance Measurement

Laser Rangefinder: up to 1,000 m, ±1 m accuracy

Scene Mode

Jungle, Recognition

Video Recording

Yes

Audio Recording

Yes

Magnification

Thermal Channel - 2.5x – 28x / Optical Channel - 5.5x – 22x

Detector type

Thermal Detector - 12μm VOx Uncooled Focal Plane Array / Digital Sensor - 3840×2160, 1/88” Progressive Scan CMOS

FFC (Flat Field Correction)

Auto, Manual, External Correction

Highest Temperature Spot Tracking

Yes

Standby Mode

Yes

Refresh rate

25 Hz

Resolution

1280 × 1024

Laser Wavelength

905 nm

Detection Range (6' object)

3,100 m

Snapshot

Yes

Lens system

Thermal Channel - 60 mm; F1.0 / Optical Channel - 60 mm, F2.2

NETD

Less than 18 mK (25°C, F#=1.0)

Field of view (H × X)

Thermal Channel - 14.6° × 11.7° / Optical Channel - 6.9° × 4.1°

Diopter adjustment range

-5 to +3

Monitor

1920×1080, 0.49 inch, OLED, 50 FPS

Display

Day, Night, Auto

Storage

64 GB EMMC

Battery Type

Two 18650 rechargeable battery (removable)

Wi-Fi

Yes

Battery Life (Operating)

Up to 8 hours continuous running (@25°C, WiFi, IR and LRF off)

Power supply

5 VDC/2 A, USB Type-C interface. Supports external power supply.

Operating Temperature Range

-20°C to 55°C (-4°F to 131°F)

Weight

1.05 kg (2.31 Ib)

Protection Level

IP67 (Waterproof)

Data Sheet

Included:

4x 18650 Rechargeable Battery
Battery Charger
USB Cable
Power Adapter
Tripod Adapter
Quick Start Guide
User Manual
Lens Cloth
Neck Strap
